6.5 Run the PINGME.C Sample Program
Connect the crossover cable from your computer ’s Ethernet port to the RCM3360/
RCM3370 board’s RJ-45 Ethernet connector. Open this sample program from the SAM-
PLES\TCPIP\ICMP folder, compile the program, and start it running under Dynamic C.
The crossover cable is connected from your computer ’s Ethernet adapter to the RCM3360/
RCM3370 board’s RJ-45 Ethernet connector. When the program starts running, the green
LINK light on the RCM3360/RCM3370 module should be on to indicate an Ethernet con-
nection is made. (Note: If the LNK light does not light, you may not be using a crossover
cable, or if you are using a hub perhaps the power is off on the hub.)
The next step is to ping the board from your PC. This can be done by bringing up the MS-
DOS window and running the pingme program:
ping 10.10.6.101
or by Start > Run
and typing the entry
ping 10.10.6.101
Notice that the yellow ACT light flashes on the RCM3360/RCM3370 module while the
ping is taking place, and indicates the transfer of data. The ping routine will ping the board
four times and write a summary message on the screen describing the operation.
6.6 Running Additional Sample Programs With Direct Connect
The following sample programs are in the Dynamic C SAMPLES\RCM3360\TCPIP
folder.
? BROWSELED.C —This program demonstrates a basic controller running a Web page.
Two “device LEDs” are created along with two buttons to toggle them. Users can use
their Web browser to change the status of the lights. The DS3 and DS4 LEDs on the
Prototyping Board will match those on the Web page. As long as you have not modified
the TCPCONFIG 1 macro in the sample program, enter the following server address in
your Web browser to bring up the Web page served by the sample program.
http://10.10.6.100.
Otherwise use the TCP/IP settings you entered in the TCP_CONFIG.LIB library.
? MBOXDEMO.C —The optional LCD/keypad module (see Appendix C) must be plugged
in to the Prototyping Board when using this sample program. This program demon-
strates sending e-mail messages that are then shown on the LCD/keypad module dis-
play. The keypad is used to scroll through a menu to view the messages, flip to other
messages, mark messages as read, and delete messages. When a new e-mail arrives, an
LED on the LCD/keypad module turns on, and then turns off once the message has
been marked as read. A log of all e-mail actions is kept, and can be displayed in the
Web browser. All current e-mails can also be read with the Web browser.
? PINGLED.C —This program demonstrates ICMP by pinging a remote host. It will flash
LEDs DS3 and DS4 on the Prototyping Board when a ping is sent and received.
58
RabbitCore RCM3360/RCM3370
